Welcome to the Linear AK-11 manual, a comprehensive guide for installers and system managers․ This manual covers installation, programming, and operation of the AK-11 keyless entry system, designed for access control applications․ Learn about its features, such as the rugged cast aluminum enclosure, backlit keys, and programmable entry codes․ Discover how to maximize its capabilities for secure and efficient access management․
Overview of the Linear AK-11 System
The Linear AK-11 is a digital keyless entry system designed for access control applications․ It features a rugged cast aluminum enclosure with bright, easy-to-read keys and programmable entry codes․ The system supports up to 480 codes, ranging from 1 to 6 digits, and includes LED status indicators for power, access, and lockout conditions․ It also offers advanced features like anti-passback, alarm shunt outputs, and solid-state outputs for enhanced functionality․ Ideal for securing doors or gates, the AK-11 is durable and versatile, making it a reliable solution for access control needs․
Key Features and Benefits
The Linear AK-11 offers a robust feature set, including a programmable keypad with up to 480 entry codes, customizable relay outputs, and LED status indicators․ Its anti-passback feature enhances security by preventing code reuse within a set time․ The system also includes solid-state outputs for signaling events like forced entry or door ajar conditions․ With a durable cast aluminum enclosure and bright keys, the AK-11 provides reliable, long-lasting access control for various applications, ensuring both security and convenience․
Components and Specifications
The Linear AK-11 includes a rugged cast aluminum enclosure, 12-24V AC/DC power input, and programmable relays․ It features two solid-state outputs, EEPROM memory, and operates in extreme temperatures․
Hardware Components
The Linear AK-11 features a rugged cast aluminum enclosure for durability, housing a backlit keypad with bright yellow graphics․ It includes two Form C relays (5A and 1A) and two solid-state outputs for auxiliary functions․ The system supports a 12-24V AC/DC power supply and includes EEPROM memory for code retention․ Mounting options include pedestal or wall installation, with security bolts for secure setup․ The enclosure dimensions are 4․00W x 5․50H x 3․00D, ensuring compact and versatile placement․
Technical Specifications
The AK-11 operates on 12-24V AC/DC power, with a typical current draw of 10mA and maximum 150mA․ It supports up to 480 programmable entry codes, each 1-6 digits long․ The system includes two relays (5A and 1A) and two solid-state outputs (100mA)․ Operating temperature ranges from -30°C to 65°C (-22°F to 149°F)․ The enclosure measures 4․00W x 5․50H x 3․00D, ensuring durability and compact installation for various access control environments․
Installation Guidelines
Mount the AK-11 keypad on a pedestal or wall using security bolts․ Ensure proper wiring with 18 AWG for power and 22 AWG for other connections․ Ground the unit to prevent static damage and follow safety precautions for installation near gates or doors to avoid hazards․
Mounting Options
The Linear AK-11 keypad offers flexible mounting options for various installations․ It can be securely mounted on a standard pedestal using four security bolts and locking nuts․ For wall mounting, use appropriate fasteners to attach the backplate directly to the surface․ When installing on concrete walls, concrete wedge anchors or molly anchors are recommended․ Ensure the keypad is positioned for clear visibility and safe operation, keeping it far enough from gates to prevent user contact while operating․
Wiring Diagram
The wiring diagram outlines connections for power, inputs, and outputs․ Connect the power supply to the + and ─ terminals, ensuring proper polarity․ The DOOR SENSE/INHIBIT input connects to a door switch or timer․ The REQUEST-TO-ENTER input links to a pushbutton or keyswitch․ Outputs include relays for door strikes and solid-state outputs for signaling․ Use 18 AWG wire for power and grounding, ensuring the earth ground terminal is connected to prevent static damage․ Follow the diagram carefully for correct installation․
Power Connections
The Linear AK-11 operates on a 12-24 Volt AC or DC power supply․ Connect the positive wire to the + terminal and the negative wire to the ౼ terminal, ensuring proper polarity․ For AC-powered units, ground one side of the transformer secondary to the unit’s earth ground terminal․ Use 18 AWG wire for power connections and grounding to avoid damage․ The system draws 10 mA typical and up to 150 mA maximum․ Power can be sourced from an access device or a separate supply․
Programming Instructions
The Linear AK-11 allows easy programming via keypad․ Enter programming mode using * and # keys․ Add or modify entry codes and set system options efficiently․
Entering Programming Mode
To enter programming mode on the Linear AK-11, press and hold the key, then press the # key, and release both․ Finally, press the key again within 3 seconds․ The LEDs will blink, confirming programming mode activation․ Use this mode to configure entry codes, adjust settings, and customize system behavior․ Follow the on-screen prompts carefully to avoid errors during the process․
Adding New Entry Codes
To add a new entry code, enter programming mode by pressing the [] key, then the [#] key, and release both․ Press the [] key again within 3 seconds․ Enter the desired 1-6 digit code using the keypad and press [*] to store it․ The system allows up to 480 codes, each programmable to activate specific relays․ Ensure the code is unique and test it immediately after saving to confirm functionality․
Programming Options
The Linear AK-11 offers flexible programming options to customize system behavior․ Program up to 480 entry codes, each 1-6 digits, to activate specific relays or outputs․ Set timed or toggled relay operations and enable features like anti-passback, which prevents reusing codes within a programmed time frame․ Configure solid-state outputs for conditions such as forced entry or lockout․ Programming options also include door sense or inhibit inputs, request-to-enter functionality, and alarm shunt outputs for seamless integration with security systems․
System Operation
The Linear AK-11 operates with LED status indicators, anti-passback features, and entry code management․ LEDs show power, access, and lockout status, ensuring clear system feedback and secure access control․
LED Status Indicators
The Linear AK-11 features two LED indicators for system status monitoring․ The left LED glows red to indicate power and turns green upon successful access․ The right LED lights yellow during lockout, signaling excessive incorrect code attempts․ These visual cues provide immediate feedback, enhancing user experience and system security․ The LEDs are essential for diagnosing operational states and ensuring efficient access control management․
Anti-Passback Feature
The Linear AK-11 includes an anti-passback feature to enhance security by preventing the reuse of an entry code within a programmed time frame․ This ensures that a single code cannot grant multiple accesses in quick succession, reducing the risk of unauthorized entry․ The system enforces a waiting period before the same code can be used again, adding an extra layer of protection for controlled access points․
Entry Code Management
The Linear AK-11 allows up to 480 programmable entry codes, ranging from 1 to 6 digits, providing flexible access control․ Codes can activate one or both relay outputs, enabling customized access permissions․ The system also supports a manager’s entry code log, tracking recent entries for monitoring․ This feature ensures secure and organized access management, with options to set time-restricted codes for enhanced security and convenience․
Advanced Features
The Linear AK-11 includes advanced features like solid-state outputs, alarm shunt functionality, and request-to-enter inputs, enhancing security and system integration for access control applications․
Alarm Shunt Output
The Alarm Shunt Output activates when access is granted, preventing false alarms․ It connects to the alarm contacts on the door or gate, ensuring the system doesn’t trigger during authorized entry․ This feature enhances security by maintaining alarm integrity while allowing legitimate access, providing a seamless and reliable access control experience․
Solid-State Outputs
The Linear AK-11 features two solid-state outputs capable of switching up to 100 mA to common․ These outputs can signal conditions such as forced entry, door ajar, lockout, or request-to-enter․ They are programmable to activate in response to specific events, providing flexible control and monitoring options for access management and alarm systems․ These outputs enhance the system’s versatility in handling various access control scenarios efficiently․
Request-to-Enter Input
The Linear AK-11 includes a Request-to-Enter input, enabling codeless entry for authorized personnel․ This feature allows connection to a pushbutton or fire access keyswitch, granting access without requiring a code․ It ensures quick and secure entry in specific situations, such as emergencies or authorized access, while maintaining system security and convenience․
Troubleshooting and Maintenance
This section provides solutions for common issues and maintenance tips to ensure optimal performance of the Linear AK-11 system, addressing keypad, connectivity, and hardware-related concerns effectively․
Common Issues and Solutions
Address common issues like keypad lockouts, incorrect entry codes, and LED status malfunctions․ If the keypad locks due to excessive wrong attempts, wait 2 minutes before retrying․ For invalid codes, re-enter carefully or verify programming․ LED indicators help diagnose problems: red for power, green for access, and yellow for lockouts․ Regularly inspect wiring connections to prevent malfunctions․ Ensure all terminals are secure and free from corrosion for reliable system performance and user convenience․
Maintenance Tips
Regularly clean the keypad surface to prevent dirt buildup and ensure smooth operation․ Inspect and secure all wiring connections to avoid loose terminals․ Check the power supply for stable voltage and ensure the ground connection is secure to prevent static damage․ Periodically test the LED indicators and solid-state outputs to confirm proper functionality․ Lubricate hinges and moving parts of the enclosure to maintain durability․ Schedule annual inspections to ensure optimal performance and longevity of the system․
Warranty and Compliance
The Linear AK-11 is backed by a limited warranty covering manufacturing defects․ It complies with FCC regulations and environmental standards, ensuring reliable performance and legal operation․
Linear Limited Warranty
The Linear AK-11 is protected by a limited warranty covering manufacturing defects for a specified period, typically one year from purchase․ This warranty ensures repair or replacement of faulty components․ Proper installation and usage are required for warranty validity․ Damages from misuse or improper installation are excluded․ Contact Linear’s customer service for warranty claims or inquiries․ Registration may be required for warranty activation, ensuring your system remains protected and functional․
FCC Notice and Compliance
The Linear AK-11 complies with FCC regulations, specifically Part 15, ensuring minimal radio frequency interference․ Operation in residential areas is permitted without causing harmful interference․ Proper installation is crucial to maintain compliance․ Changes or modifications to the device without approval may void its compliance status․ Users must adhere to FCC rules to avoid legal consequences․ This notice underscores the importance of correct usage to ensure regulatory adherence and system reliability․
The Linear AK-11 manual provides essential guidance for successful installation, programming, and operation, ensuring secure access control․ For further learning, refer to additional resources․
Final Thoughts
The Linear AK-11 manual offers a detailed guide to installing, programming, and maintaining the system․ Its robust design and advanced features, such as programmable entry codes and anti-passback functionality, ensure secure access control․ With clear instructions and troubleshooting tips, users can maximize the system’s efficiency․ Whether for residential or commercial use, the AK-11 provides reliable performance and flexibility, making it a trusted solution for modern access management needs․
Additional Resources
For further assistance, visit the official Linear Nortek website for the latest AK-11 manual and software updates․ Download the PDF manual from trusted sources like ManualMachine or ControlledProducts․ Contact Linear customer support at (760) 438-7000 or toll-free numbers for technical help․ Explore troubleshooting guides and FAQs on their site; Additional resources include instructional videos and user forums for shared experiences and solutions․
